    Induction furnace


    Current position：Home >  Products > Induction furnace




























    • 2500c high temperature induction heating vacuum CVD furnace
      •

    • 2500c high temperature induction heating vacuum CVD furnace
      •













    • 2500c high temperature induction heating vacuum CVD furnace
      •

    • 2500c high temperature induction heating vacuum CVD furnace
      •











    2500c high temperature induction heating vacuum CVD furnace



The equipment is batch type induction furnace, mainly used for CVD in carbon carbon material and carbon composite material or graphite parts material.













     Introduction







    •


	1.Application:




	The equipment is batch type induction furnace, mainly used for CVD in carbon carbon material and carbon composite material or graphite parts material.




	2.Configuration:




	380V±5%，50Hz/60Hz 3 phase 5 wire




	One control cabinet to one furnace, the facility equipped of mixed gas control system, cooling tower for optional.































					           Model            Parameter






					Lab usage






					Production usage










					NTI-CJL-42L






					NTI-CJL-100L






					NTI-CJL-196L






					NTI-CJL-339L






					NTI-CJL-803L










					Working size






					mm






					300×600






					400x800






					500×1000






					600x1200






					800x1600










					Heating type






					/






					IF induction heating










					Crucible






					/






					Graphite










					Control type






					/






					Thyristor control or IGBT control ( optional )










					HT zone capacity






					L






					42






					100






					196






					339






					803










					Loading weight






					g






					  HT zone capacity × density (g/cm3)×1000        Remark：1L=1000cm3










					Ultimate vacuum






					Pa






					50










					IF power






					Kw






					100






					150






					200






					250






					350










					Max. working temperature






					℃






					2500






					2500






					2500






					2500






					2500










					Vapor deposition temperature






					℃






					Within 2000℃






					Within 2000℃






					Within 2000℃






					Within 2000℃






					Within 2000℃










					Temperature uniformity






					℃






					±5






					±5






					±10






					±10






					±10










					Overall dimension






					mm






					5000x6000






					5500x6500






					6000x7000






					6500x7500






					7000x8000










					Weight






					Kg













































					Working environment






					/






					Vacuum, Argon, Nitrogen, Hydrogen atmosphere protection










					Vapor deposition environment






					/






					300-3000pa air pressure, charging into CH?CH?CH?, CH4, C3H6.



















      •
